1270 / 1330nm Duplex XFP Transceiver , XFP 10G ER 40km Transmission Distance

Moduleland Technology Co., Ltd.
Contact Now

1270 / 1330nm Duplex XFP Transceiver , XFP 10G ER 40km Transmission Distance

  • 1
  • 2

Brand Name : MODULELAND

Model Number : TXBLXG40D-2733/TXBLXG40D-3327

Certification : CE RoHS FCC TUV

Place of Origin : Hanoi, Vietnam

MOQ : 1 Piece

Supply Ability : 10000 Piece/Pieces per Month

Packaging Details : Packaging Details: 1or 5PCS /Plastic tray, 1PC/Gift box Delivery Detail:Shipped in 1 days after payment

Price : Negotiable

Distance : 40km

Wavelength : 1270/1330nm

Data Rate : 10Gb/s

Connector : LC

Power supply : +3.3V

Operating temperature : 0°C to 70°C

Mode : Single SMF

Vcsel : Yes

DDM/DOM : Yes

Port : VietNam

Contact Now

1270 / 1330nm Duplex XFP Transceiver , XFP 10G ER 40km Transmission Distance

1. Features:

  Built-in 1270/1330 WDM

  Support multi protocol from 9.95Gb/s to 11.3Gb/s

  Hot pluggable 30 pin connector

  Compliant with XFP MSA

  Transmission distance of 40km over single mode fiber

  1270nm or 1330nm CWDM DFB Laser.

  Duplex LC connector

  2-wire interface for management and diagnostic monitor

  XFI electrical interface with AC coupling

  Single power supply voltages : +3.3V

  Temperature range 0°C to 70°C

  Power dissipation: <1.5W

  RoHS Compliant Part



​2. Applications:

  10GBASE-ER/EW Ethernet
  1200-Mx-SN-I 10G Fibre Channel
  Other optical links



3. Description:

         TXPLXG40-2733/3327 Bi-directional 10Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification. They comply with 10-Gigabit Ethernet 10GBASE-LR/LW per IEEE 802.3ae, SONET OC-192 /SDH and 10G Fibre Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.



4. Optical Parameters(TOP = 0 to 70°C)



Parameter Symbol Min Typ Max Unit Ref.
Transmitter
Operating Date Rate BR 9.95   11.3 Gb/s
Bit Error Rate BER     10-12
Maximum Launch Power PMAX 0   5 dBm 1
Optical Center Wavelength TXPLXG40-2733 λ 1260 1270 1280 nm
TXPLXG40-3327 1320 1330 1340
Optical Extinction Ratio ER 3.5     dB
Spectral Width Δλ     1 nm
Sidemode Supression ratio SSRmin 30     dB
Rise/Fall Time (20%~80%) Tr/Tf     50 ps
Average Launch power of OFF Transmitter POFF     -30 dBm
Tx Jitter Txj Compliant with each standard requirements
Optical Eye Mask   IEEE802.3ae 2
Receiver
Operating Date Rate BR 9.95   11.3 Gb/s
Receiver Sensitivity Sen     -16 dBm 2
Maximum Input Power PMAX 0     dBm 2
Optical Center Wavelength TXPLXG40-2733 λC 1320 1330 1340 nm
TXPLXG40-3327 1260 1270 1280
Receiver Reflectance Rrx     -27 dB
LOS De-Assert LOSD     -15 dBm
LOS Assert LOSA -30     dBm
LOS Hysteresis LOSH 0.5   5 dB



5. About us
        Moduleland locating in Hanoi Vietnam, is a factory based manufacturer of optical transceivers covering various types widely applied to WAN, LAN, SAN, Fiber Channel, FTTX, etc.

6. Packaging & Shipping

1270 / 1330nm Duplex XFP Transceiver , XFP 10G ER 40km Transmission Distance

1270 / 1330nm Duplex XFP Transceiver , XFP 10G ER 40km Transmission Distance1270 / 1330nm Duplex XFP Transceiver , XFP 10G ER 40km Transmission Distance



Our Services

1. Warranty

Five years Warranty, three monthes free exchange and one year free repairing.

2. OEM, ODM are welcome.

3. Free sample will be provided.

Free samples under a certain value are available,with freight cost collect.

4. Any Inquire is welcome.

Any inquire will be replied within 24 hours.

5. After-sales service.
a. From the beginning of production till the successful delivery, we will track on time and post you the status.
b. When the goods arrived, if you have question after inspection, please feel free to contact us, we'll provide solution.



FAQ

Q:What payment terms do you accept?

A:T/T,L/C at sight,Western Union are acceptable. Other payment terms are negotiable.

Q:what is the lead time?

A: For standard products,we keep enough stock,cqn ship out in 1-3 days after PO confirmation.For big quantity and special products,Please check lead time with our sales representative.

Q:What are the shipping ways can you offer?

A:For small quantity we ship by Express like DHL,FedEX,TNT,UPS, EMS etc. For large quantity we can use airshipment ot other appointed method by clients.

Q:What euipments can your products be compatible with?

A:Our products can be compatible with all market brand.

Q:How to place an order?

A:1> Confirm order details with our sales representatives.
    2> Proforma Invoice confirmed, the order will be arranged upon receipt of your payment.
    3> Confirm shipping details and dispatch goods, tracking number will be sent to you promptly after the shipment is                  picked up.
    4> We will help to track your goods until you receive them safely.
